OMRON
SKU: E6C2CWZ6C100PR2MOMS
On Order
E6C2-CWZ6C 100P/R 2M – Enkoder, artımlı, 100puls, 5-24 VDC, NPN, 2m kablolu
E6C2-CWZ6C 100P/R 2M
| Model No | E6C2CWZ6C100PR2MOMS |
|---|---|
| SKU | E6C2CWZ6C100PR2MOMS |
| HS Code | 9032.9000.90 |
| Category | Rotary Encoders |
Description
Enkoder, artımlı, 100puls, 5-24 VDC, NPN, 2m kablolu
Specifications
| Model No | E6C2-CWZ6C 100P/R 2M |
| SKU | E6C2CWZ6C100PR2MOMS |
| HS CODE | 9032.9000.90 |
| DATA SHEET | Datasheet (EN) |
Specifications
| Model | Incremental encoder |
|---|---|
| Programmable | No |
| Housing material | Aluminium |
| Max. pulses per revolution | 100 |
| Signal outputs of rotary encoder | A+B+0 |
| Type of electric connection | Cable |
| Explosion safety category for gas | None |
| Explosion safety category for dust | None |
| Standard for interfaces | Other |
| Degree of protection (IP) | IP64 |
| Number of steps per revolution | 100 |
| Number of revolutions | 0 |
| Type of shaft encoder | Full shaft |
| Diameter axle | 5.979 mm |
| Impulse rate per cycle | 100 |
| Type of transmission medium | Copper |
| Physical measurement principle | Optical |
| Degree of protection (NEMA) | Other |
| Construction size | 50 mm |
Technical data supplied by OMRON and classified to ETIM 10.
