OMRON
SKU: G9SA321T15ACDC24
On Order
G9SA-321-T15 AC/DC24 – Safety relay unit, 3PST-NO (Category 4), 5 A, SPST-NC aux, DPST-NO 1 to 15sec ‘OFF-delay’ category 3 outputs, 1 or 2 channel input
G9SA-321-T15 AC/DC24
| Model No | G9SA-321-T15 AC/DC24 |
|---|---|
| SKU | G9SA321T15ACDC24 |
| HS Code | 8536.4900.99 |
| Category | Safety Logic Control Systems |
Description
Safety relay unit, 3PST-NO (Category 4), 5 A, SPST-NC aux, DPST-NO 1 to 15sec 'OFF-delay' category 3 outputs, 1 or 2 channel input
Specifications
| Model No | G9SA-321-T15 AC/DC24 |
| SKU | G9SA321T15ACDC24 |
| HS CODE | 8536.4900.99 |
| DATA SHEET | Datasheet (EN) |
Specifications
| Product Type | Safety relay unit |
|---|---|
| Current | 5 A |
| Output | DPST-NO 1 to 15sec 'OFF-delay' category 3 outputs |
| Input | 1 or 2 channel input |
| Width | 45 mm |
| Model | Basic device |
| Height | 76 mm |
| Depth | 111 mm |
| Release-delay | 1 s |
| With approval according to UL | Yes |
| Voltage type (supply voltage) | AC/DC |
| With detachable clamps | No |
| With start input | No |
| With feedback circuit | No |
| Number of outputs, safety related, undelayed, with contact | 3 |
| Number of outputs, safety related, delayed, with contact | 2 |
| Number of outputs, safety related, undelayed, semiconductors | 0 |
| Number of outputs, safety related, delayed, semiconductors | 0 |
| Number of outputs, signalling function, undelayed, with contact | 1 |
| Number of outputs, signalling function, delayed, with contact | 0 |
| Number of outputs, signalling function, undelayed, semiconductors | 0 |
| Number of outputs, signalling function, delayed, semiconductors | 0 |
| Type of electric connection | Screw connection |
| Suitable for rail mounting | Yes |
| With muting function | No |
| Type of safety according to IEC 61496-1 | 4 |
| With approval for BG BIA | No |
| Voltage type (operating voltage) | AC/DC |
| Rated switch current | 5 A |
| Suitable for monitoring of magnetic switches | Yes |
| Suitable for monitoring of proximity switches | Yes |
| Suitable for monitoring of emergency-stop circuits | Yes |
| Suitable for monitoring of optoelectronic protection equipment | Yes |
| Suitable for monitoring of position switches | Yes |
| Suitable for monitoring of tactile sensors | Yes |
| Suitable for monitoring of valves | Yes |
| Performance level according to EN ISO 13849-1 | Level e |
| Stop category according to IEC 60204 | Other |
| Supply voltage AC 50 Hz | 20.4 V |
| Supply voltage AC 60 Hz | 20.4 V |
| Supply voltage DC | 20.4 V |
| Operating voltage AC 50 Hz | 0 V |
| Operating voltage AC 60 Hz | 0 V |
| Operating voltage DC | 0 V |
| Evaluation inputs | 1-channel or 1- and 2-channel |
| SIL according to IEC 61508 | 3 |
| With approval for Tu00dcV | No |
Technical data supplied by OMRON and classified to ETIM 10.
Features
- 3PST-NO (Category 4)
- SPST-NC aux
