OMRON
SKU: K3MA2104R
On Order
K3MA-L-C 24VAC/VDC
| Model No | K3MA-L-C 24VAC/VDC |
|---|---|
| SKU | K3MA2104R |
| Category | Digital Panel Indicators |
Specifications
| Mounting method | Front mounting |
|---|---|
| Width | 96 mm |
| Model | Direct measurement |
| Height | 48 mm |
| Depth | 80 mm |
| Measured value memory | Yes |
| Display | LCD |
| Harmonics measurement | No |
| Power factor | No |
| Apparent power | No |
| Step angle (cos phi) | No |
| Number of digital inputs | 0 |
| Number of digital outputs | 1 |
| Number of analogue inputs | 1 |
| Number of analogue outputs | 0 |
| Voltage type (supply voltage) | AC/DC |
| Supporting protocol for PROFIBUS | No |
| Supporting protocol for Modbus | No |
| Supporting protocol for other bus systems | No |
| Degree of protection (IP), front side | Other |
| Number of Ethernet connections | 0 |
| Ampere meter | No |
| Reactive power meter | No |
| With rotational speed meter | No |
| Frequency meter | No |
| Pulse counter | No |
| Voltmeter | No |
| Effective power measurement device | No |
| With communication interface RS-485 | No |
| Connectable conductor cross section solid-core | 0.08 mmu00b2 |
| Supporting protocol for PROFINET IO | No |
| Suitable for RJ plug | No |
| Calibrated | No |
| Pulse output | None |
| Measurement type load profile | No |
| Accuracy class active energy according to IEC 62053-22 | Other |
| Accuracy class reactive energy according to IEC 62053-23 | Other |
| Sampling frequency | 2 Hz |
| Number of voltage measurement inputs | 0 |
| Number of current measurement inputs | 0 |
| Supporting protocol for IEC 61850 Ethernet | No |
| Supporting protocol for OPC UA PubSub | No |
| With audit logging (audit log) | No |
| With firmware signature | No |
| With logging of security events (security event log) | No |
| With Role Based Access Control (RBAC) | No |
| Web server with HTTPS transfer protocol | No |
| With communication interface KNX | No |
| Wth communication interface M-Bus | No |
| Remote display | No |
Technical data supplied by OMRON and classified to ETIM 10.
