OMRON
SKU: NXEC0112
On Order
Machine Automation Controllers
NX-EC0112 – 1 Incremental Enkoder NPN Giriş, Faz A ve B: Tek-faz 500 kHz (Faz farkı Puls Giriş x4: 125 kHz), Faz Z: 125 kHz, 12 mm genişlik
NX-EC0112
| Model No | NX-EC0112 |
|---|---|
| SKU | NXEC0112 |
| HS Code | 8517.6200.00 |
| Category | Machine Automation Controllers |
Description
1 Incremental Enkoder NPN Giriş, Faz A ve B: Tek-faz 500 kHz (Faz farkı Puls Giriş x4: 125 kHz), Faz Z: 125 kHz, 12 mm genişlik
Specifications
| Model No | NX-EC0112 |
| SKU | NXEC0112 |
| HS CODE | 8517.6200.00 |
| DATA SHEET | Datasheet (EN) |
Specifications
| Input | 1 Incremental Enkoder NPN Input |
|---|---|
| Input 2 | Faz A ve B: Tek-faz 500 kHz (Faz farkı Puls Input x4: 125 kHz) |
| Dimension | 12 mm width |
| Width | 12 mm |
| Height | 100 mm |
| Depth | 71 mm |
| Frequency measurement | Yes |
| Suitable for safety functions | No |
| Voltage type (supply voltage) | DC |
| Supporting protocol for LON | No |
| Number of HW-interfaces industrial Ethernet | 0 |
| Number of HW-interfaces RS-232 | 0 |
| Number of HW-interfaces RS-422 | 0 |
| Number of HW-interfaces RS-485 | 0 |
| Number of HW-interfaces serial TTY | 0 |
| Number of HW-interfaces USB | 0 |
| Number of HW-interfaces parallel | 0 |
| Number of HW-interfaces other | 1 |
| With optical interface | No |
| Supporting protocol for TCP/IP | No |
| Supporting protocol for ASI | No |
| Supporting protocol for PROFIBUS | No |
| Supporting protocol for CAN | No |
| Supporting protocol for INTERBUS | No |
| Supporting protocol for KNX | No |
| Supporting protocol for Modbus | No |
| Supporting protocol for Data-Highway | No |
| Supporting protocol for DeviceNet | No |
| Supporting protocol for SUCONET | No |
| Supporting protocol for other bus systems | Yes |
| Number of functions | 1 |
| Suitable for counting | Yes |
| Suitable for weighing | No |
| Suitable for welding control | No |
| Suitable for pressure control | No |
| Suitable for NC | No |
| Suitable for SSI | No |
| Suitable for electronic positioning | No |
| Suitable for CNC | No |
| Suitable for incremental data detection | Yes |
| Suitable for detection absolute value | No |
| Suitable for flux controller | No |
| Suitable for flux measurement | No |
| Suitable for path controller | No |
| Suitable for cam controller | No |
| Suitable for flying saw | No |
| Suitable for multi-axis control | No |
| Suitable for single-axis controller | No |
| Suitable for multi-axis positioning | No |
| Suitable for single-axis positioning | No |
| Suitable for rail mounting | Yes |
| Explosion safety category for gas | None |
| Explosion safety category for dust | None |
| Fieldbus connection over separate bus coupler possible | Yes |
| System accessory | Yes |
| Appendant operation agent (Ex ia) | No |
| Appendant operation agent (Ex ib) | No |
| Degree of protection (IP) | IP20 |
| Supporting protocol for SERCOS | No |
| Supporting protocol for INTERBUS-Safety | No |
| Number of interfaces PROFINET | 0 |
| Number of HW-interfaces wireless | 0 |
| Front built-in possible | No |
| Rack-assembly possible | No |
| Wall mounting/direct mounting | No |
| Radio standard Bluetooth | No |
| Radio standard WLAN 802.11 | No |
| Function block automatic reset | No |
| Function block contactless working protection installation | No |
| Function block operating mode selection | No |
| Function block emergency stop | No |
| Function block restart blockage | No |
| Function block access control | No |
| Function block affirm push button | No |
| Function block 2-hand switching | No |
| IO link master | No |
| Performance level according to EN ISO 13849-1 | Level a |
| Contactor control function block | No |
| Supporting protocol for AS-Interface Safety at Work | No |
| Supporting protocol for DeviceNet Safety | No |
| Supporting protocol for EtherNet/IP | Yes |
| Supporting protocol for Foundation Fieldbus | No |
| Supporting protocol for PROFINET CBA | No |
| Supporting protocol for PROFINET IO | No |
| Supporting protocol for PROFIsafe | No |
| Supporting protocol for SafetyBUS p | No |
| Supply voltage DC | 20.4 V |
| Suitable for temperature control | No |
| Radio standard GPRS | No |
| Radio standard GSM | No |
| Mobile communications standard 3G (UMTS) | No |
| SIL according to IEC 61508 | None |
| Degree of protection (NEMA) | Other |
| Supporting protocol for EtherCAT | Yes |
| Certified for UL hazardous location class I | No |
| Certified for UL hazardous location class II | No |
| Certified for UL hazardous location class III | No |
| Certified for UL hazardous location division 1 | No |
| Certified for UL hazardous location division 2 | No |
| Certified for UL hazardous location group A (acetylene) | No |
| Certified for UL hazardous location group B (hydrogen) | No |
| Certified for UL hazardous location group C (ethylene) | No |
| Certified for UL hazardous location group D (propane) | No |
| Certified for UL hazardous location group E (metal dusts) | No |
| Certified for UL hazardous location group F (carbonaceous dusts) | No |
| Certified for UL hazardous location group G (non-conductive dusts) | No |
Technical data supplied by OMRON and classified to ETIM 10.
Features
- Faz Z: 125 kHz
