OMRON
SKU: S8NR3000F
On Order
S8NR-S36024-A0L2-IL3
| Model No | S8NR-S36024-A0L2-IL3 |
|---|---|
| SKU | S8NR3000F |
| Category | Power Supplies |
Specifications
| Width | 181 mm |
|---|---|
| Height | 183 mm |
| Depth | 58.7 mm |
| Built-in height | 183 mm |
| Power consumption | 400 VA |
| Suitable for wall mounting | Yes |
| Built-in width | 181 mm |
| Suitable for distribution board | No |
| Suitable for safety functions | No |
| Width in number of modular spacings | 10.3 |
| Voltage type (supply voltage) | AC |
| Power output | 360 W |
| Output voltage stabilized | Yes |
| Type of electric connection | Other |
| Suitable for rail mounting | No |
| Stabilized | Yes |
| Degree of protection (IP) | IP67 |
| Direct mounting possible | Yes |
| 1st secondary output voltage | 24 V |
| 2nd secondary output voltage | 24 V |
| 3rd secondary output voltage | 24 V |
| Secondary voltage adjustable | Yes |
| Rated supply voltage AC 50 Hz | 100 V |
| Rated supply voltage AC 60 Hz | 100 V |
| Short-circuit-proof | Yes |
| Performance level according to EN ISO 13849-1 | None |
| Max. output current 1 | 10 A |
| Max. output current 2 | 10 A |
| Max. output current 3 | 10 A |
| Nominal value output voltage 1 | 24 V |
| Nominal value output voltage 2 | 24 V |
| Nominal value output voltage 3 | 24 V |
| Nominal value output current 1 | 10 A |
| Nominal value output current 2 | 10 A |
| Nominal value output current 3 | 10 A |
| SIL according to IEC 61508 | None |
| Degree of protection (NEMA) | Other |
Technical data supplied by OMRON and classified to ETIM 10.
